Cantilever Storage Racks hold long or awkward material that will not sit on a pallet - pipe, tube, bar, angle sections, timber, boards and sheet. With no front upright in the way, material loads along the full bay length. We build up to 1000 kg per arm, arms 600 to 1000 mm, columns 15 ft to 20 ft.
Anything long that will not sit sensibly on a pallet: pipe, tube, bar, angle sections, timber, boards and sheet. Because there is no front upright in the way, material can be loaded along the full length of the bay.
Up to 1000 kg per arm in our standard build, with arm lengths from 600 mm to 1000 mm and columns from 15 ft to 20 ft. The load must be spread across arms rather than concentrated at the arm tip, which is where most overloading happens in practice.
Single-sided racks stand against a wall. Double-sided racks stand in open floor and store from both faces, which is usually the better value per tonne stored if you have the aisle for it.
Arm end stops are available and we recommend them for pipe and anything round. Arms can also be supplied inclined for the same reason.
